Pendulum Feeder

Processing ability: 0–25 t/h

Feeding granularity: 35–50 mm

Applied material: granular material, powdery material, etc

Email us: sell@hxjq.com

The Function and Application of Pendulum Feeder:

Pendulum Feeder suitable for concentrating coal chemical industry and other departments, makes the grain delivery to various set of accepting the material from the store chute by the filter. The pendulum feeder is not suitable for delivering the dry power of the too big material or else, it may appear the fly-ash pollution or the Jam of the output.

pendulum_feeder

The Detailed Introduction to Pendulum Feeder:

The pendulum feeder is one of the most common machines among the mining equipment. It is widely used in the material feeding process of the rock particles and it is also called shaker feeder. This machine is able to send the materials from the material cabin to the material receiving machine in a even, regular and continuous manner and it can be used for feeding materials to ball mill or belt conveyor.

pendulum_feeder

The Performance Characteristics of Pendulum Feeder:

Pendulum feeder is suitable in industries like ore dressing, coal, chemistry and many others. The granular material will be sent from store chute to discharge device via the funnel. Pendulum feeder is not suitable for conveying dry powder or material with too big granularity, otherwise, dust pollution and discharge mouth blocking phenomenon would occur.

Technical Parameter

Product Name
Pendulum feeder
Pendulum feeder
Product size
400×400
600×600
Swing times(time/min-1)
47
45.8
Discharge opening(mm)
Width
400
600
Height
400
600
Swing journey(mm)
0-170
0-220
Max.Feeding Size(mm)
35
50
Processing capacity(t/h)
0-12
3-25
Motor
Model
Y90S-4
Y100L-4
Power(kw)
1.1
2.2
Total weight(kg)
269
558
