The Main Handling Materials of Coal Dryer:
Coal dryer is used for drying materials with humidity or granularity in the industries of mineral dressing, building material, metallurgy and chemical, which can dry sawdust, palm shell, wood chips, bagasse, straw, vinasse , slag, coal powder, mining powder, clay, sand, limestone and so on.
The Main Components of Coal Dryer:
This dryer is mainly composed of the revolving body, lifting plate, driving device, supporting device, sealing ring and other components.
The Performance Characteristics of Coal Dryer:
- Temperature induction monitor, uniform vibration and airproof setting, which improve performance and productivity efficiently.
- Adopts assembled hoist board so as to exchange heat fully and lower the energy consumption .
- According to the characteristics of different fertilizers, we have arranged the second granulation zone reasonably so as to improve the granulation effect.
What can you get?
Latest Price List/Free Customized Solution/Maintenance & Installation Guide
-
Free customized solutions
Customize different models according to your needs（Small, medium, and large machine）.
-
Factory direct sales
We have three production bases, guarantee 100% factory price of all products, and support export to
all over the world.
-
24-hour online service
We have professional customer service staff, ready to answer your questions about our products.
Technical Parameter
|
Spec./m
(Dia.×Length）
|
Shell Cubage
（m³）
|
Capacity
（t/h）
|
Installation
Obliquity
（%）
|
Highest Inlet
Air Temperature
（℃）
|
Main Motor
（kw)
|
Weight
（t）
|
|
Φ1.2×8.0
|
9.0
|
1.9～2.4
|
3～5
|
700～800
|
7.5
|
9
|
|
Φ1.2×10
|
11.3
|
2.4～3.0
|
3～5
|
700～800
|
7.5
|
11
|
|
Φ1.5×12
|
21.2
|
4.5～5.7
|
3～5
|
700～800
|
15
|
18.5
|
|
Φ1.5×14
|
24.7
|
5.3～6.6
|
3～5
|
700～800
|
15
|
19.7
|
|
Φ1.5×15
|
26.5
|
5.7～7.1
|
3～5
|
700～800
|
15
|
20.5
|
|
Φ1.8×12
|
30.5
|
6.5～8.1
|
3～5
|
700～800
|
18.5
|
21.5
|
|
Φ1.8×14
|
35.6
|
7.6～9.5
|
3～5
|
700～800
|
18.5
|
23
|
|
Φ2.2×12
|
45.6
|
9.7～12.2
|
3～5
|
700～800
|
22
|
33.5
|
|
Φ2.2×14
|
53.2
|
11.4～14.2
|
3～5
|
700～800
|
22
|
36
|
|
Φ2.2×16
|
60.8
|
13.0～16.2
|
3～5
|
700～800
|
22
|
38
|
|
Φ2.4×14
|
63.3
|
13.5～16.9
|
3～5
|
700～800
|
37
|
45
|
|
Φ2.4×18
|
81.4
|
17.4～21.7
|
3～5
|
700～800
|
37
|
49
|
|
Φ2.4×20
|
90.4
|
19.3～24.1
|
3～5
|
700～800
|
45
|
54
|
|
Φ2.4×22
|
99.5
|
21.2～26.5
|
3～5
|
700～800
|
45
|
58
|
|
Φ2.6×24
|
127.4
|
27.2～34.0
|
3～5
|
700～800
|
55
|
73
|
|
Φ3.0×20
|
141.3
|
30.1～37.7
|
3～5
|
700～800
|
75
|
85
|
|
Φ3.0×25
|
176.6
|
37.7～47.1
|
3～5
|
700～800
|
75
|
95
|
|
Φ3.2×25
|
201
|
42.9～53.6
|
3～5
|
700～800
|
90
|
110
|
|
Φ3.6×28
|
285
|
60.8～76.0
|
3～5
|
700～800
|
160
|
135
|
Technical parameters of indirect heat dryer:
Shell
diameter
×shell
Length
Items |
Inside
diameter
of outer
shell
（mm） |
Inside
diameter
of inner
shell
（mm） |
Shell
Length
（m） |
Shell
cubage
（m³） |
Shell
obliquity |
Lifting
blade
form |
Highest
inlet air
temperature
（℃） |
Dimensions
（m） |
| Φ1.5×15m |
1500 |
500 |
15 |
20.27 |
3-5% |
Lifting form |
850 |
16.2×2.7×2.7 |
| Φ1.5×17m |
17 |
22.97 |
18.2×2.7×2.7 |
| Φ1.5×19m |
19 |
25.68 |
20.0×2.9×2.9 |
| Φ1.8×21m |
1800 |
650 |
21 |
35.91 |
3-5% |
Lifting form |
850 |
22.5×2.7×2.7 |
| Φ1.8×23m |
23 |
39.33 |
24.5×2.9×2.9 |
| Φ1.8×25m |
25 |
42.75 |
26.5×2.9×2.9 |
| Φ2.2×21m |
2200 |
800 |
21 |
58.10 |
3-5% |
Lifting form |
850 |
---- |
| Φ2.2×23m |
23 |
63.61 |
| Φ2.2×25m |
25 |
69.15 |
Note:processing Capacity May Vary With Different Materisla Aan Feeding Sizes.
